Partial Dependence Plot — lets-plot

A partial dependence plot (PDP) showing the marginal effect of one feature on the predicted outcome of a machine learning model. The plot displays how predictions change as a feature varies across its range, while averaging over the effects of all other features. This visualization is essential for understanding the relationship between individual features and model predictions in interpretable machine learning.

Partial Dependence Plot rendered with lets-plot

Python source (lets-plot)

""" anyplot.ai
pdp-basic: Partial Dependence Plot
Library: letsplot 4.9.0 | Python 3.13.13
Quality: 94/100 | Updated: 2026-05-15
"""

import os

import numpy as np
import pandas as pd
from lets_plot import *
from sklearn.datasets import make_regression
from sklearn.ensemble import GradientBoostingRegressor
from sklearn.inspection import partial_dependence


LetsPlot.setup_html()

# Theme tokens
THEME = os.getenv("ANYPLOT_THEME", "light")
PAGE_BG = "#FAF8F1" if THEME == "light" else "#1A1A17"
ELEVATED_BG = "#FFFDF6" if THEME == "light" else "#242420"
INK = "#1A1A17" if THEME == "light" else "#F0EFE8"
INK_SOFT = "#4A4A44" if THEME == "light" else "#B8B7B0"

# Okabe-Ito colors
BRAND = "#009E73"
ACCENT = "#C475FD"

# Train a model for partial dependence
np.random.seed(42)
X, y = make_regression(n_samples=500, n_features=5, noise=20, random_state=42)
feature_names = ["Temperature", "Humidity", "Pressure", "WindSpeed", "Altitude"]

model = GradientBoostingRegressor(n_estimators=100, max_depth=4, random_state=42)
model.fit(X, y)

# Compute partial dependence for Temperature (feature 0)
feature_idx = 0
feature_name = feature_names[feature_idx]
pdp_result = partial_dependence(model, X, features=[feature_idx], kind="both", grid_resolution=80)

feature_values = pdp_result["grid_values"][0]
avg_pd = pdp_result["average"][0]

# Get individual conditional expectations (ICE) for uncertainty
ice_lines = pdp_result["individual"][0]
lower_bound = np.percentile(ice_lines, 10, axis=0)
upper_bound = np.percentile(ice_lines, 90, axis=0)

# Create DataFrame for plotting
df_pdp = pd.DataFrame(
    {"feature_value": feature_values, "partial_dependence": avg_pd, "lower": lower_bound, "upper": upper_bound}
)

# Sample ICE lines for visualization (show a subset)
n_ice_lines = 50
ice_indices = np.random.choice(ice_lines.shape[0], n_ice_lines, replace=False)
ice_data = []
for i, idx in enumerate(ice_indices):
    for j, fv in enumerate(feature_values):
        ice_data.append({"feature_value": fv, "ice_value": ice_lines[idx, j], "line_id": i})
df_ice = pd.DataFrame(ice_data)

# Get rug data (sample of training feature values for distribution)
rug_sample = np.random.choice(X[:, feature_idx], size=100, replace=False)
rug_height = (avg_pd.max() - avg_pd.min()) * 0.08
y_min = avg_pd.min() - rug_height / 2
y_max = avg_pd.min() + rug_height / 2
df_rug = pd.DataFrame(
    {"x": rug_sample, "y_start": np.full(len(rug_sample), y_min), "y_end": np.full(len(rug_sample), y_max)}
)

# Custom theme
anyplot_theme = theme(
    plot_background=element_rect(fill=PAGE_BG, color=PAGE_BG),
    panel_background=element_rect(fill=PAGE_BG),
    panel_grid_major=element_line(color=INK, size=0.2),
    panel_grid_minor=element_blank(),
    axis_title=element_text(color=INK, size=20),
    axis_text=element_text(color=INK_SOFT, size=16),
    axis_line=element_line(color=INK_SOFT, size=0.5),
    plot_title=element_text(color=INK, size=24, face="bold"),
    legend_background=element_rect(fill=ELEVATED_BG, color=INK_SOFT),
    legend_text=element_text(color=INK_SOFT, size=16),
    legend_title=element_text(color=INK, size=16),
)

# Create the partial dependence plot
plot = (
    ggplot()
    + geom_ribbon(aes(x="feature_value", ymin="lower", ymax="upper", fill="Confidence Band"), data=df_pdp, alpha=0.25)
    + geom_line(
        aes(x="feature_value", y="ice_value", group="line_id", color="Individual"), data=df_ice, alpha=0.2, size=0.5
    )
    + geom_line(aes(x="feature_value", y="partial_dependence", color="Main PDP"), data=df_pdp, size=2.5)
    + geom_segment(
        aes(x="x", y="y_start", xend="x", yend="y_end", color="Data Distribution"), data=df_rug, alpha=0.6, size=1.2
    )
    + scale_color_manual(values={"Main PDP": BRAND, "Individual": ACCENT, "Data Distribution": ACCENT})
    + scale_fill_manual(values={"Confidence Band": ACCENT})
    + labs(
        x=f"{feature_name} (standardized)",
        y="Partial Dependence (predicted outcome)",
        title="pdp-basic · letsplot · anyplot.ai",
        color="Elements",
        fill="",
    )
    + anyplot_theme
    + ggsize(1600, 900)
    + theme(legend_position="top", legend_direction="horizontal")
)

# Save as PNG and HTML
ggsave(plot, f"plot-{THEME}.png", w=4800, h=2700, unit="px", path=".")
ggsave(plot, f"plot-{THEME}.html", path=".")

Part of Partial Dependence Plot on anyplot.ai.
