An Exponential Moving Average (EMA) overlay chart displays price data with one or more EMA lines that give greater weight to recent prices, making them more responsive to new information than simple moving averages. The EMA calculation applies an exponential weighting factor that decreases with each older data point, allowing traders to identify trends faster. This technical indicator is fundamental in trading for spotting trend direction, dynamic support/resistance levels, and crossover signals.
// anyplot.ai
// indicator-ema: Exponential Moving Average (EMA) Indicator Chart
// Library: echarts 6.1.0 | JavaScript 22.23.2
// Quality: 92/100 | Created: 2026-09-02
const t = window.ANYPLOT_TOKENS;
// --- Data (in-memory, deterministic) ----------------------------------------
// Simple LCG so the sample data is reproducible without Math.random().
let seed = 42;
function rand() {
seed = (seed * 1103515245 + 12345) & 0x7fffffff;
return seed / 0x7fffffff;
}
const PERIODS = 120;
const SHORT_PERIOD = 12;
const LONG_PERIOD = 26;
const startDate = new Date(Date.UTC(2026, 0, 5));
const dates = [];
for (let i = 0; i < PERIODS; i++) {
const dt = new Date(startDate.getTime() + i * 86400000);
dates.push(
`${dt.getUTCFullYear()}-${String(dt.getUTCMonth() + 1).padStart(2, "0")}-${String(dt.getUTCDate()).padStart(2, "0")}`,
);
}
// Daily close price: a random walk with three drift regimes — an opening
// pullback, then a rally, then a second pullback — so the EMA lines produce
// both a golden cross (bullish) and a death cross (bearish) naturally rather
// than by construction.
const close = [148.5];
for (let i = 1; i < PERIODS; i++) {
let drift;
if (i < PERIODS * 0.3) drift = -0.4;
else if (i < PERIODS * 0.7) drift = 0.45;
else drift = -0.35;
const noise = (rand() - 0.5) * 3.2;
close.push(Math.max(close[i - 1] + drift + noise, 5));
}
function ema(values, period) {
const k = 2 / (period + 1);
const out = new Array(values.length).fill(null);
const seedAvg = values.slice(0, period).reduce((a, b) => a + b, 0) / period;
out[period - 1] = seedAvg;
for (let i = period; i < values.length; i++) {
out[i] = values[i] * k + out[i - 1] * (1 - k);
}
return out;
}
const emaShort = ema(close, SHORT_PERIOD);
const emaLong = ema(close, LONG_PERIOD);
// Crossover points: short EMA moving from below to above the long EMA is a
// golden cross (bullish); above to below is a death cross (bearish).
const goldenCrosses = [];
const deathCrosses = [];
for (let i = LONG_PERIOD; i < PERIODS; i++) {
const prevDiff = emaShort[i - 1] - emaLong[i - 1];
const diff = emaShort[i] - emaLong[i];
if (prevDiff <= 0 && diff > 0) goldenCrosses.push({ coord: [dates[i], emaShort[i]], name: "Golden Cross" });
if (prevDiff >= 0 && diff < 0) deathCrosses.push({ coord: [dates[i], emaShort[i]], name: "Death Cross" });
}
// --- Init ---------------------------------------------------------------------
const chart = echarts.init(document.getElementById("container"));
// --- Option ---------------------------------------------------------------------
chart.setOption({
animation: false,
backgroundColor: "transparent",
color: t.palette,
title: {
text: "indicator-ema · javascript · echarts · anyplot.ai",
left: "center",
top: 20,
textStyle: { color: t.ink, fontSize: 22, fontWeight: 500 },
},
tooltip: {
trigger: "axis",
axisPointer: { type: "cross" },
valueFormatter: (value) => `$${Number(value).toFixed(2)}`,
},
legend: {
data: ["Close", `EMA (${SHORT_PERIOD})`, `EMA (${LONG_PERIOD})`],
top: 66,
left: "center",
textStyle: { color: t.ink, fontSize: 16 },
itemWidth: 22,
itemHeight: 12,
},
grid: {
left: 90,
right: 60,
top: 130,
bottom: 90,
containLabel: true,
},
xAxis: {
type: "category",
data: dates,
boundaryGap: false,
name: "Date",
nameLocation: "middle",
nameGap: 50,
nameTextStyle: { color: t.inkSoft, fontSize: 14 },
axisLabel: {
color: t.inkSoft,
fontSize: 13,
rotate: 45,
interval: (index) => index % 10 === 0,
},
axisLine: { lineStyle: { color: t.inkSoft } },
axisTick: { show: false },
splitLine: { show: false },
},
yAxis: {
type: "value",
scale: true,
name: "Price (USD)",
nameLocation: "middle",
nameGap: 60,
nameTextStyle: { color: t.inkSoft, fontSize: 14 },
axisLabel: { color: t.inkSoft, fontSize: 13, formatter: (v) => `$${v}` },
axisLine: { show: false },
axisTick: { show: false },
splitLine: { lineStyle: { color: t.grid } },
},
series: [
{
name: "Close",
type: "line",
data: close,
symbol: "none",
lineStyle: { width: 3.5, color: t.palette[0] },
itemStyle: { color: t.palette[0] },
z: 3,
},
{
name: `EMA (${SHORT_PERIOD})`,
type: "line",
data: emaShort,
symbol: "none",
lineStyle: { width: 1.75, color: t.palette[2] },
itemStyle: { color: t.palette[2] },
z: 2,
markPoint: {
symbolSize: 40,
label: { show: false },
data: [
...goldenCrosses.map((p) => ({ ...p, symbol: "triangle", itemStyle: { color: t.palette[7] } })),
...deathCrosses.map((p) => ({ ...p, symbol: "triangle", symbolRotate: 180, itemStyle: { color: t.palette[4] } })),
],
},
},
{
name: `EMA (${LONG_PERIOD})`,
type: "line",
data: emaLong,
symbol: "none",
lineStyle: { width: 1.75, color: t.palette[3] },
itemStyle: { color: t.palette[3] },
z: 2,
},
],
});
Runnable source as JSON, for any HTTP client: https://api.anyplot.ai/specs/indicator-ema/echarts/code. Any spec id and library id listed in llms-full.txt fit the same URL shape; every URL below is complete and callable.
{
"spec_id": "indicator-ema",
"language": "javascript",
"library": "echarts",
"page": "https://anyplot.ai/indicator-ema/javascript/echarts",
"hub": "https://anyplot.ai/indicator-ema",
"code_json": "https://api.anyplot.ai/specs/indicator-ema/echarts/code",
"spec_json": "https://api.anyplot.ai/specs/indicator-ema",
"render_light_png": "https://storage.googleapis.com/anyplot-images/plots/indicator-ema/javascript/echarts/plot-light.png",
"render_dark_png": "https://storage.googleapis.com/anyplot-images/plots/indicator-ema/javascript/echarts/plot-dark.png",
"interactive_light_html": "https://storage.googleapis.com/anyplot-images/plots/indicator-ema/javascript/echarts/plot-light.html",
"interactive_dark_html": "https://storage.googleapis.com/anyplot-images/plots/indicator-ema/javascript/echarts/plot-dark.html",
"quality_score": 92.0,
"license": "MIT",
"guide": "https://anyplot.ai/llms.txt"
}Part of Exponential Moving Average (EMA) Indicator Chart on anyplot.ai.
