Scatter Plot with Text Labels Instead of Points — Pygal

A scatter plot where data points are represented by text labels instead of markers. Each label is positioned at its corresponding coordinates, making the text itself the visual element. This visualization is particularly useful for displaying named entities in 2D space, such as word embeddings, dimensionality reduction outputs, or any scenario where identifying individual items by name is more important than seeing their relative density.

Scatter Plot with Text Labels Instead of Points rendered with Pygal

Renders

Python source (Pygal)

""" anyplot.ai
scatter-text: Scatter Plot with Text Labels Instead of Points
Library: pygal 3.1.0 | Python 3.13.13
Quality: 83/100 | Created: 2026-05-17
"""

import os

import pygal
from pygal.style import Style


THEME = os.getenv("ANYPLOT_THEME", "light")
PAGE_BG = "#FAF8F1" if THEME == "light" else "#1A1A17"
INK = "#1A1A17" if THEME == "light" else "#F0EFE8"
INK_MUTED = "#6B6A63" if THEME == "light" else "#A8A79F"
BRAND = "#009E73"

IMPRINT = ("#009E73", "#C475FD", "#4467A3", "#BD8233", "#AE3030", "#2ABCCD", "#954477")

custom_style = Style(
    background=PAGE_BG,
    plot_background=PAGE_BG,
    foreground=INK,
    foreground_strong=INK,
    foreground_subtle=INK_MUTED,
    colors=IMPRINT,
    title_font_size=28,
    label_font_size=18,
    major_label_font_size=16,
    legend_font_size=16,
    value_font_size=14,
    stroke_width=2,
)

# Data: Product positioning (Price Competitiveness vs. Feature Completeness)
products = [
    {"x": 2.1, "y": 3.2, "label": "Budget Start-up Kit"},
    {"x": 3.5, "y": 2.8, "label": "Standard Pro"},
    {"x": 4.2, "y": 4.1, "label": "Premium Suite"},
    {"x": 1.8, "y": 4.5, "label": "Full Enterprise"},
    {"x": 3.9, "y": 1.9, "label": "Lite Essentials"},
    {"x": 2.7, "y": 3.7, "label": "Growth Package"},
    {"x": 4.6, "y": 3.3, "label": "Elite Plus"},
    {"x": 1.2, "y": 2.1, "label": "Basic Tier"},
    {"x": 3.3, "y": 4.8, "label": "Advanced Max"},
    {"x": 4.8, "y": 2.5, "label": "Performance Edge"},
]

# Plot
chart = pygal.XY(
    style=custom_style,
    width=4800,
    height=2700,
    title="scatter-text · Python · pygal · anyplot.ai",
    x_title="Price Competitiveness",
    y_title="Feature Completeness",
    show_legend=False,
    show_dots=False,
    show_y_guides=True,
    dots_size=0,
)

# Add data series with text labels
chart.add(
    "Products",
    [
        {
            "value": (p["x"], p["y"]),
            "label": p["label"],
            "color": BRAND,
        }
        for p in products
    ],
)

# Set axis ranges
chart.range = (0, 5.5)

# Save
chart.render_to_png(f"plot-{THEME}.png")
with open(f"plot-{THEME}.html", "wb") as f:
    f.write(chart.render())

Part of Scatter Plot with Text Labels Instead of Points on anyplot.ai.
